Opencart eCommerce conversion tracking with Google Analytics 4 and GTM

In this Opencart tutorial, we are going through Opencart eCommerce conversion tracking with Google Analytics 4 (GA4) and google tag manager. First, we will install the google tag manager(GTM) in Opencart, then set up the DataLayer code on the checkout success page, then finalize with showing data in Google Analytics 4 dashboard.

Install the Google Tag Manager (GTM) in Opencart

We hope you already have the gmail account. Following are the steps to install the google tag manager in the Opencart:

  • Log in to the (you need a Gmail account for this).
  • Click “Create Account”
  • Enter the details, in the Container name you can add the website URL, and in the “Target platform” select the “Web”, then click the “Create” button.
    Tag manager account
  • It will show you the code like below to add to the opencart website, copy this code.
Install Tag manager

View Video: Add HTML, google analytics, tag manager, third party JS code in Opencart

Add GTM to Opencart

  • Login to your Opencart admin
  • Click Extensions in left menu >> Extensions >> in “Choose the extension type” select “Analytics”
  • Click Install if the “Google Analytics” module is not installed and then edit it, if it is already installed then edit it.
  • Then, paste the Google Tag Manager code in the “Google Analytics Code” field.
  • Finally, click Save blue button
Opencart GTM installation

Connect Google Analytics with GTM

  • Login to
  • Account setup: If you already have others GA account click “Admin” in the left menu and click “Create Account”, else you will see the Create Account page, where you can enter the Account Name.
    Google Analytics Account name
  • Property setup: An account can contain one or more properties. For eg: webocreation is an Account and under that, we can have and as properties. So, enter the Property name. Then, click “Show advanced options“. Activate the Universal Analytics property and enter the website URL. Select “Create both a Google Analytics 4 and a Universal Analytics property“. Then click Next.
Property Setup GA
  • About your business: enter the details of your business.
  • Click Create and in the popup choose your country and click accept checkbox and click the “I Accept” button
  • Then, select the data stream to start collecting data, as we are collecting data of website so we select “Web”
    Data Stream Google Analytics
  • Then enter details to set up data stream, enter the website URL and stream name, then click create stream button.
    Web Stream GA 4
  • Now, see the “Tagging instructions” section and click the “Use existing on-page tag”, then click the Google Tag Manager, where you will see the steps for you.
    Google Tag Manager - Connection to Google Analytics
  • Now, let’s go to and select the container that you created earlier and do the steps as below
    • Open the Google Tag Manager container that’s implemented on your page.
    • Click Tags > New.
    • Click Tag Configuration and select GA4 Configuration.
    • Enter this Measurement ID: G-C87SJVP2EX. (Your Id will be different)
    • Select to trigger the tag on All Pages (or on the subset of pages you want to measure).
    • Save and publish your tag configuration.

Test whether GA4 is firing from GTM

  • Click the Preview button
    Preview Test GA4
  • Enter your website URL in the popup and click “Connect”
    Connect tag assistant to website
  • If you see “Google Analytics GA4 configuration” in the tag fired list then it means your tags are firing from the website.
    Tags fired GTM GA4
  • Go to google analytics dashboard, then click the Realtime in the left menu, if you see some reports then it means. everything is connected properly with Google Analytics 4 and Google Tag manager.
Google Analytics 4 Dashboard

Set up a custom tag, triggers, and events in GTM for success page for Opencart

Setup tags for Purchase Event

Go to tag manager, click the Tags, click New, enter the tag name as “Purchase Event”, click the “Tag Configuration”, select the “Google Analytics: Universal Analytics”. In the Track type, select the Event. In the Event tracking parameters, enter purchase in the category, and purchase in action. In the Google Analytics Settings, select the GA tracking ID.

Purchase event on the GA

Triggers for the purchase events

Go to tag manager, click the Triggers, click New, enter the name like “Success URL”, click in the “Trigger Configuration”, choose “Page View” on the trigger type. Choose “Some Page Views”, then select “Page Path”, then select “contains” and enter “success”. Finally, click Save

Success tags and trigger for Opencart

With these steps, we are doing a good start, in our next blog posts we will show you how to create custom datalayer code for the checkout success page in Opencart, probably we will provide you the Opencart module and similarly add other custom events for purchase and pass multiple variables like price, product id/name, etc to the google analytics. Then, we finalize by checking GA4 eCommerce tracking. Please let us know if you have issues or concerns and ideas for GA4 and Opencart, we will share our experiences. You can follow my Twitter account @rupaknpl and subscribe to our youtube channel Opencart tutorials. Similarly, keep on visiting my personal blog where you will find lots of free modules.
