Payment Gateway Provided By TechProcess Solutions Ltd help

This post is for the developer of a payment gateway provided by TechProcess Solutions Ltp and can be helpful for the development of modules for Opencart

Checksum Document for PHP

Transaction Detail Checksum Facility
On Payment Gateway
Provided By TechProcess Solutions Ltd

TPSL has a checksum facility for providing security at transaction time. This is one of the types of integration we have. In this type of integration, TPSL will provide API to the merchant, which they have to deploy at their end. A checksum value will be generated using this API. Please find the below mentioned detailed process below.

Process for Checksum

1. The merchant has to deploy the API given by TPSL at their end.
2. All the necessary request parameters will be sent to this API.
3. This API will generate a checksum value.
4. At the request time, this checksum value will come to TPSL’s end with the request parameter as per Annexure 01.
5. When the request reaches TPSL’s side TPSL will once again generate the checksum value using the request parameter received from the Merchant.
6. If the value of the checksum matches at both ends, then the transaction will be forwarded to the respective bank.
7. Once TPSL receives the response from the bank, TPSL generates a checksum value with the response parameter that will be sent to the merchant.
8. Once TPSL sends the response to the merchant along with the checksum value, the merchant will generate a checksum using the response parameter received from TPSL.
9. If the checksum value matches at the merchant side using API then that transaction will return as a Transaction Success. After that check the auth status as per annexure 03:If, auth status=0300 is for a successful transaction or auth status=0399 is for failed transactions
10. If checksum mismatches, that transaction will be considered a Failed/Fraud transaction.

Learn about: Free invoice generator online

Technical Process Flow:

01. The merchant has to share the request URL (From which the transaction request will come) with TPSL.TPSL will configure the same at the TPSL end and validate transaction time for security purposes.
02. The merchant can hit the below URL for Transaction Processing




1. PHP 5 or greater
2. cUrl

Step 1: Files and Directory Verification

1.1. Please make sure a total of 5 files are provided to you. (Request.php, getcheck.php,
1.2. Response.php, keystoretekp.pem, and
1.3. Make sure these files are placed under the same directory except
1.4. It is not compulsory to place files under the directory provided by Techprocess.
1.5. Please ensure the following values are available inside the file.
1.5.1. BillerId= [Represent the Merchant ID provided by TPSL.]
1.5.2. ResponseUrl= [Represent the Response URL of the merchant.]
1.5.3. CRN= [Currency.]
1.5.4. CheckSumKey= [Unique key provided by TPSL.]
1.5.5. CheckSumGenUrl= [URL provided by TPSL.]
1.5.6. TPSLUrl= [TPSL Payment gateway URL.]

Step 2: Implementation

2.1. Make sure the file is not accessible from the browser.
2.2. For testing, the default URL will be present for “TPSLUrl=” in the file.
2.3. You can change this URL once you get the new URL from TPSL for Live Transactions.
2.4. Change the following in with the details TPSL has provided.
2.5. Make sure there are any spaces at the beginning and the end of each value of
2.6. Follow Screen:1

Screen: 1

2.7. Copy Request.php, getcheck.php, Response.php, and keystoretekp.pem to the desired directory.
2.8. Open getcheck.php and change the Property file path to the path where you have placed your property file. Make a similar change in Response.php

Follow Screen:2.

Screen: 2

2.9. Now, look for “curl_setopt($ch,
line and change the URL to where your getcheck.php and Response.php file is placed. Make sure you replace the filename.php with the respective file names. e.g.

For getcheck.php:
curl_setopt($ch, CURLOPT_REFERER,’’);

For response.php:
curl_setopt($ch, CURLOPT_REFERER,’’);

3. Step 3: Important things to remember.
3.1 Do not modify “keystoretekp” file.
3.2 Do not modify any code in any of the files.
3.3 To get response values, you can check the “Response.php” file. Do not bypass any of the procedures from the “Response.php” file.
3.4 Under response.php you will get the following array once the transaction is done.

[0] => T1234 [Biller Id]
[1] => 1 [Transaction ID]
[2] => 00
[3] => NA
[4] => 1 [Amount]
[5] => 470 [Bank code]
[6] => NA
[7] => NA
[8] => INR
[9] => NA
[10] => NA
[11] => NA
[12] => NA
[13] => 18-07-2011 10:12:18 [Timestamp]
[14] => 0399 [Could be 0300/0399] 0300: Success transaction. 0399: Failed transaction.
[15] => NA
[16] => 1 [Market code]
[17] => 1 [Account Number]
[18] => NA
[19] => NA
[20] => NA
[21] => NA
[22] => NA
[23] => NA
[24] => NA
[25] => 292697030925

3.4 Please remember integration will be handled in two ways.
a) Test server transaction.
b) Live server transaction.
For both types, you need to perform configuration in the same files/fields which are provided to you.

Request.php: Do not require any kind of configuration.
getcheck.php: Configuration required.
Response.php: Configuration required. Configuration required.
Keystoretekp.pem: Do not require any kind of configuration.

Configuration Required in Files Revised for both types

i. Set the property file path.
ii. Set curl_opt REFERER path to your domain name.
iii. Set curl_opt CURLOPT_CAINFO path to the certificate that is provided to you. Please note Test and Live certificates are different.

iv. Set the property file path.
v. Set curl_opt REFERER path to your domain name.
vi. Set curl_opt CURLOPT_CAINFO path to the certificate which is provided to you. Please note Test and Live certificates are different.
vii. Change BillerID to the one provided to you.
viii. Change Responseurl to the one where your Response.php file is located.
ix. Change CheckSumKey to the one that is provided to you.
x. Change CheckSumGenUrl when the Live URL is provided to you.
xi. Change TPSLUrl when the Live URL is provided to you.

For more details related to Request and Response please refer to Annexure.

Annexure 01: Checksum Request Parameter (From Merchant to TPSL)

Sample Value Size Type Description
Transaction Id 1234556 8 (string) Mandatory MERCHANT unique reference number
Market Code 1234 10 (String) Mandatory Extra information from the merchant for product details with alphanumeric plus _
Account No 123-334444 OR
1 200 (String) Mandatory It will be the account number of customers provided by MERCHANT or if MERCHANT don’t want to pass account no then they need to pass the constant value as 1.
Payment Amount 500.00 8 Mandatory It will be the transaction amount
Bank Code 300 5 (String) Mandatory It will be a bank Code as per Annexure 08.
Property file path D:\TechProcess\Property\ 150 (String) Mandatory Merchant needs to pass the complete or relative path of the property file residing in the system.

Annexure 02: Checksum Response Parameter (From TPSL to Merchant)

Parameter Sample Value Size Type Description
MERCHANT ID L123 6 Character MERCHANT id provided by TPSL to MERCHANT.
CustomerID 9871234567 20 varchars MERCHANT unique transaction id.
TxnreferenceNo NA NA NA TPSL unique transaction ID
BankReferenceNo NA NA NA Banks unique transaction ID.
TxnAmount 700 15 Varchar Transaction Amount provided by MERCHANT (SRC AMT field in TPSL system).
BankID 300 3 Numeric Bank Id provided by TPSL.
BankMERCHANTID NA NA NA It will be the MERCHANT id of MERCHANT provided by the bank (provided by the bank). For the rest banks, it will be “NA”.
TxnType NA NA NA This will be “NA” always.
Currency Name INR 3 Varchar This will be “INR” always.
Item Code NA NA NA This will be “NA” always.
Security Type NA NA NA This will be “NA” always.
Security ID NA NA NA This will be “NA” always.
Security Password NA NA NA This will be “NA” always.
TxnDate Date 20 Date Format DD-MM-YYYY HH:MM: SS Time and date at which TPSL sends the response. Format is
Auth Status Refer to Annexure 03
Settlement Type NA NA NA This will be “NA” always.
AdditionalInfo1 7072006 20 Varchar This will be the market code.
AdditionalInfo2 102-102976395 100 Varchar This will be the account number.
AdditionalInfo3 NA NA Date This will be “NA” always.
AdditionalInfo4 NA NA Varchar This will be “NA” always.
AdditionalInfo5 NA NA Varchar This will be “NA” always.
AdditionalInfo6 NA NA Varchar This will be “NA” always.
AdditionalInfo7 NA NA Varchar This will be “NA” always.
ErrorStatus NA NA NA This will be “NA” always
Error Description NA or 000 100 NA or Varchar This will be either “NA” or respective error messages.
CheckSum 123456789 50 Varchar This will be a unique checksum number as per logic.

Note: The checksum that is generated is 12 digit number.

Annexure 03:

AUTHSTATUS Status Reason Proposed Transaction
“0300” Success Successful Transaction
“0399” Invalid Authentication at Bank Cancel Transaction

Test Account
